Intel 10 Gigabit Optical Module

Fiber optic adapter knowledge brief Published 14 Dec 2020

Prepared for preliminary research by the DANI ALONSO OPTICAL knowledge desk. Confirm connector interfaces, sleeve materials, polish, loss budgets and installation requirements against current standards and product documentation.

Intel 10G SFP+ optical modules, such as the E10GSFPSR, provide high-speed, reliable 10 Gigabit Ethernet connectivity for data centers and enterprise networks.Overview

Intel 10G SFP+ optical modules are designed to deliver 10 Gigabit Ethernet (10 GbE) and 1 Gigabit Ethernet (1 GbE) connectivity over fiber optic networks. The E10GSFPSR model supports short-range (SR) multi-mode fiber connections and is compatible with Intel Ethernet Converged Network Adapters, including the X520 series, ensuring seamless integration and reliable performance .

Key Features
  • Data Rates: Supports both 10 GbE and 1 GbE for flexible deployment .
  • Distance: Can extend Ethernet connections up to 300 meters over multi-mode fiber, suitable for connecting servers to Top of Rack (ToR) or End of Row (EoR) switches .
  • Form Factor: Small Form-Factor Pluggable Enhanced (SFP+) design allows hot-pluggable installation in high-density environments .
  • Signal Integrity: Uses VCSEL (Vertical-Cavity Surface-Emitting Laser) technology, providing immunity to electromagnetic interference (EMI) and radio frequency interference (RFI), .
  • Power and Size: Compact and lightweight, consuming less power than copper alternatives, with a tighter bend radius and longer reach .
  • Security and Reliability: Fiber optics are resistant to electrical interference and network tapping, enhancing secure data transmission .
  • Diagnostics: Built-in digital diagnostic functions allow for real-time monitoring of temperature, voltage, and optical power for easier troubleshooting .
  • Compliance: RoHS-6 compliant, ensuring environmentally safe construction .
Use Cases
  • Data Centers: Connecting servers to switches in high-density racks.
  • Enterprise Networks: Extending Ethernet connections over longer distances than copper cabling allows.
  • Virtualization and SAN/LAN Networking: Provides scalable, high-speed connections for virtualized environments .
  • Harsh Environments: Fiber optics provide stable performance in areas with electrical noise or interference .
Compatibility and Installation
  • Only Intel-certified SFP+ modules are guaranteed to work with Intel Ethernet adapters like the X520 series .
  • When connecting two Intel SFP+ devices back-to-back, ensure matching speed and duplex settings to avoid performance issues .
  • Hot-pluggable design allows for easy installation and replacement without powering down devices . Intel 10G SFP+ optical modules, particularly the E10GSFPSR, are factory new, genuine Intel products, ensuring compatibility, reliability, and long-term performance for enterprise and data center networking applications .
