Add a box to the side of the cable tray

Use a cable tray box mount or spider bracket to securely attach the box to the side of the tray, ensuring stable cable routing and system integrity.What is a Cable Tray Box Mount

A cable tray box mount is a specialized accessory designed to attach electrical boxes, junction boxes, or panels directly to a cable tray system. Its main purpose is to provide stable support for the box while allowing cables to transition safely from the tray into connected equipment without interference or damage . This ensures organized cable management and maintains the integrity of the electrical system.

Types of Box Mounts

• Spider Brackets: Ideal for smaller trays, these brackets use slotted holes and fold-over tabs to secure the box to walls, ceilings, or machinery .
• Heavy-Duty Mounts: Suitable for larger boxes or when supporting heavy cables.
• Standard Mounts: Designed for smaller boxes or lighter installations. The mount should be compatible with the type of cable tray (ladder, ventilated, or solid-bottom) and rated to handle the cable load.

Installation Steps

1. Select the appropriate mount based on box size, cable load, and tray type.
2. Position the mount where the box will be installed, ensuring alignment with the tray and surface (wall, ceiling, or floor).
3. Secure the mount to the cable tray using bolts or clamps, and attach it to the supporting surface with appropriate anchors or fasteners.
4. Attach the electrical box to the mount, ensuring it is stable and level.
5. Route cables from the tray into the box, using cable protection accessories like covers or dividers if needed to prevent damage and maintain separation between cable types .

Additional Considerations

• Ensure proper grounding if the box or tray is metallic.
• Maintain clearance for future maintenance or expansion.
• Use cable protection accessories such as covers or radius bends to prevent insulation damage when cables exit the tray . By following these steps and using the correct box mount, you can securely add a box to the side of a cable tray while maintaining a safe, organized, and expandable cable management system .
