How to determine the breakage distance of an optical cable

Fiber optic adapter knowledge brief Published 21 Jan 2021

Prepared for preliminary research by the DANI ALONSO OPTICAL knowledge desk. Confirm connector interfaces, sleeve materials, polish, loss budgets and installation requirements against current standards and product documentation.

The most accurate way to measure the distance to a break in a fiber optic cable is by using an Optical Time Domain Reflectometer (OTDR), which calculates the distance based on reflected light pulses.Tools for Locating a Break
  1. Visual Fault Locator (VFL): Emits a visible red laser through the fiber. The break is visible where light escapes. Best for short distances (up to a few kilometers) and indoor cables .
  2. Optical Time Domain Reflectometer (OTDR): Sends light pulses down the fiber and measures backscattered and reflected light to pinpoint faults and calculate the distance to a break .
  3. Fiber Optic Power Meter and Light Source: Measures signal loss to distinguish between a break and general attenuation .
Using an OTDR to Measure Distance
  1. Connect the OTDR: Attach the OTDR to one end of the fiber. Use a launch cable if necessary to avoid dead zones at the start of the trace .
  2. Configure the Device: Enter fiber specifications, select the appropriate wavelength (commonly 1310 nm or 1550 nm), and choose pulse width based on fiber length .
  3. Run a Test Pulse: The OTDR sends light pulses along the fiber. Reflections occur at splices, connectors, bends, and breaks.
  4. Analyze the Trace: The OTDR generates a graphical trace showing backscatter levels. A sharp drop or spike indicates a break. The device calculates the distance using the speed of light in the fiber and the time taken for the reflected pulse to return .
  5. Verify and Document: Use cursor functions to manually confirm the distance to the break. Save the trace for future reference .
Accuracy and Considerations
  • OTDR distance measurements are typically accurate to ±1 meter plus 0.01% of the fiber length with proper calibration .
  • Ensure the fiber is out of service during testing, as OTDRs cannot test live fibers.
  • Launch and receive cables help eliminate dead zones and improve measurement accuracy .
Alternative Tools
  • Fiber QuickMap: A simpler tool than an OTDR that provides distance and power information for breaks and high-loss points, suitable for multimode fibers and quick troubleshooting . By using an OTDR or a Fiber QuickMap, technicians can accurately locate the distance to a break, assess splice losses, and maintain reliable fiber optic networks.
