Floor distribution box codes vary by manufacturer and model, typically including catalog numbers for 1-gang, 2-gang, and 3-gang configurations in different finishes.ABB Floor Distribution Boxes
ABB provides underfloor distribution systems suitable for offices, shops, and service environments. Their catalog includes various FDB models designed for raised floors, supporting power, data, and AV connections. Specific codes are detailed in ABB's technical catalogue, which includes recessed and pedestal floor boxes with pre-wired or floor-wired options for easy installation .
Leviton Floor Box Codes
Leviton offers a wide range of floor boxes compatible with wood, tile, vinyl, terrazzo, carpet, and concrete flooring. Their ordering guide lists catalog numbers by gang size and finish:
- 1-Gang: Cat. No (Nickel, Black, Brass)
- 2-Gang: Cat. No (Nickel, Black, Brass)
- 3-Gang: Cat. No (Nickel, Black, Brass) Each code corresponds to a specific configuration and finish, allowing precise selection for installation requirements .
Legrand Floor Boxes
Legrand floor boxes are designed for Cat 6 structured cabling systems and include backboxes made of pre-galvanized steel. While specific codes are not listed in the summary, the boxes are compatible with standard wiring accessory plates (ref 6896 80/81) and are available in recessed and self-closing lid designs .
Hubbell Floor Box Codes
Hubbell Wiring Device-Kellems provides recessed, rectangular, round, and pedestal floor boxes. Their catalog includes pre-wired and floor-wired models for power, data, and AV cables. Codes are organized by size, shape, and installation type, and detailed specifications are available in their literature and BIM objects .
Electraco Floor Distribution Boxes
Electraco lists FDBs as underground electrical outlet systems fixed to the floor. Their catalog provides product codes for different models, which can be accessed directly through their product page for ordering and installation purposes .
Summary
Floor distribution box codes are manufacturer-specific and typically organized by:
- Gang size (1-gang, 2-gang, 3-gang)
- Finish (Nickel, Black, Brass, Stainless Steel)
- Installation type (recessed, pedestal, pre-wired, floor-wired)
- Compatibility (power, data, AV, structured cabling) For precise codes, it is recommended to consult the manufacturer's catalog or ordering guide, such as ABB's technical catalogue, Leviton's ordering guide, or Hubbell's specification center, which provide complete lists of available FDB models and their corresponding codes .
