How to measure the light intensity of Indian LC pigtail fiber

Fiber optic adapter knowledge brief Published 27 Feb 2025

Prepared for preliminary research by the DANI ALONSO OPTICAL knowledge desk. Confirm connector interfaces, sleeve materials, polish, loss budgets and installation requirements against current standards and product documentation.

Use a calibrated fiber optic light source and power meter to measure the optical power transmitted through the LC pigtail fiber.Required Equipment
  • Fiber optic light source: Provides a stable optical signal at the appropriate wavelength (850 nm or 1300 nm for multimode, 1310 nm or 1550 nm for single-mode) .
  • Optical power meter: Measures the received optical power in dBm or dB, quantifying light intensity accurately .
  • Reference test cables with LC connectors: Used to set baseline measurements.
  • Cleaning supplies and inspection microscope: Ensure connectors are free of dust or debris to avoid measurement errors .
  • Mating adapters: Compatible with LC connectors for proper connection to the test equipment.
Step-by-Step Procedure
  1. Visual Inspection: Examine both ends of the LC pigtail fiber using a microscope to check for dirt or damage .
  2. Clean Connectors: Use fiber cleaning tools to remove any contaminants.
  3. Set Up Light Source: Connect the light source to one end of the fiber. Allow it to stabilize for at least 5 minutes to ensure consistent output .
  4. Connect Power Meter: Attach the power meter to the far end of the fiber. Use a reference cable to set the 0 dB baseline if required .
  5. Measure Optical Power: Record the nominal launch power from the light source and the received power at the meter. The difference gives the insertion loss or light intensity loss along the fiber .
  6. Compare to Standards: For LC connectors, an insertion loss up to ~0.75 dB is generally acceptable. Use this to verify if the fiber meets performance specifications .
  7. Document Results: Save or log the measurements for network validation or troubleshooting purposes .
Tips for Accurate Measurement
  • Ensure the light source and power meter are calibrated for the same wavelength.
  • Avoid bending or stressing the fiber during testing, as this can affect light intensity.
  • Repeat measurements if necessary to confirm consistency.
  • Use an optical loss test set (OLTS) for end-to-end testing of multiple fibers or installed channels . By following these steps, you can accurately measure the light intensity of an Indian LC pigtail fiber, ensuring reliable performance and compliance with optical network standards.
