10 Gigabit Fiber Optic Gigabit Optical Module

Fiber optic adapter knowledge brief Published 11 Oct 2023

Prepared for preliminary research by the DANI ALONSO OPTICAL knowledge desk. Confirm connector interfaces, sleeve materials, polish, loss budgets and installation requirements against current standards and product documentation.

10G SFP+ fiber optic cables use Duplex LC connectors over multimode or single-mode fiber to support distances from 300 meters to over 100 kilometers, depending on the module type.Fiber Types and Distances
  • Multimode Fiber (MMF): Typically uses OM3 or OM4 fiber with Duplex LC connectors. Common 10G SFP+ modules include 10GBASE-SR, supporting distances up to 300 meters over OM3 fiber, ideal for short-range data center connections .
  • Single-Mode Fiber (SMF): Uses OS1 or OS2 fiber with Duplex LC connectors. Modules like 10GBASE-LR support distances up to 10 km, while 10GBASE-ER and 10GBASE-ZR modules can reach 40 km to 80 km, and specialized ZRC modules can extend up to 100–120 km .
Connector Type
  • Duplex LC is the standard for most 10G SFP+ optical modules, providing a compact, high-density interface suitable for racks and switches .
  • Simplex LC is used for certain Bidi (Bi-directional) SFP+ modules, which transmit and receive on a single fiber strand using different wavelengths .
Module Compatibility
  • 10G SFP+ modules are compatible with a wide range of switches and routers from vendors like Cisco, Arista, Juniper, and Brocade .
  • Modules are available in short-range (SR), long-range (LR), extended-range (ER), and ZR/ZRC variants, each optimized for specific distances and fiber types .
  • Multi-rate SFP+ modules can support speeds up to 11.3 Gbps while maintaining backward compatibility with 1x, 2x, and 4x devices .
Active Optical Cables (AOCs)
  • For very short distances within racks, SFP+ Active Optical Cables provide a cost-effective alternative to traditional fiber transceivers, offering plug-and-play connectivity without separate transceivers .
  • AOCs are available in lengths from 1 meter to 10 meters, suitable for high-density server interconnects .
Practical Recommendations
  • Use OM3 multimode fiber for distances up to 300 meters in data centers.
  • Use OS2 single-mode fiber for distances beyond 10 km, such as campus or metropolitan networks.
  • Ensure the SFP+ module type matches the fiber type and distance requirements.
  • For short-range connections, consider direct-attach copper (DAC) cables or AOCs to reduce cost and power consumption . By selecting the appropriate fiber type, connector, and SFP+ module, you can achieve reliable 10 Gigabit Ethernet connectivity across a range of distances and deployment scenarios.
