Special connector for optical cable pulling machine

Special connectors like pulling eyes and protective socks are used to safely attach fiber optic cables to pulling machines, ensuring proper tension distribution and protection of delicate connectors.Pulling Eyes

Pulling eyes are designed to provide a rotating pulling point for fiber optic cables, allowing the cable to be pulled through conduits or ducts without damaging the cable or connectors. They distribute tension evenly across the cable assembly, which is critical for simplex and duplex fiber optic cables. For example, the PULLEYE-1 from Camplex offers a rotating pulling point and works with cable netting to protect connectors during installation .

Protective Socks

Protective socks, such as the SAFESOCK-1, are used for multi-channel fiber assemblies. These disposable overwraps fit over the ends of fiber assemblies, protecting connectors and fanouts while pulling through tight spaces or conduit bends. They are compatible with field installations and help prevent damage to sensitive fiber ends .

Mounting and Compatibility

Fiber optic cable pullers often require mounting adapters to connect the pulling machine to the cable safely. Options include:

• Remote Mounting Stands: Allow positioning of the puller away from the power source while maintaining stability .
• Hitch Mounts: Attach the puller to a standard 2" square receiver, providing a secure and adjustable connection .
• Capstan Wheels and Adjustable Tension: Pullers like the Condux or GMP models feature adjustable capstans and tension controls to match the cable type and conduit size, ensuring safe pulling without exceeding the cable's minimum bend radius .

Key Considerations

• Ensure the pulling eye or protective sock is compatible with the cable type (simplex, duplex, or multi-channel).
• Verify the maximum pulling tension of the cable puller and select connectors that can handle the load without damaging the fiber.
• Use modular or adjustable mounting systems to accommodate different jobsite layouts and conduit sizes.
• Always follow manufacturer guidelines for tension limits and installation procedures to maintain fiber integrity . By using these specialized connectors and accessories, fiber optic cable installations can be performed safely, efficiently, and without compromising the delicate fiber strands or connectors.
